Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: OEM
  • Model Number: SV1200
  • Output Power: 500 - 1000W
  • Output Type: Single
  • Size: 280 x 262 x 87mm, 280 x 262 x 87mm
  • Weight: 2.8kg
  • Input Voltage: 12V
  • Output Voltage: AC110V/220V/230V/240V
  • Type: DC/AC Inverters
  • Output Frequency: 50Hz/60Hz
  • Output Current: Load
  • Product name: Home Inverter
  • Sensitivity selector: UPS mode/inverter mode
  • Wave form: Simulated Sinewave
  • Display: LED / LCD selection
  • Warranty: 12 Months since recieving date
  • Protection: Overload, discharge,overcharge,over tempereture and short circuit
  • Noise Level: Less than 40dB
  • Color: black
  • Net weight: 2.60KG

Packaging & Delivery

Packaging Details Model: SV1200
Unit Size : 288 x 272 x 90 mm
Unit weight: 2.78 kgs
Gift box size : 312 x 128 x 332mm
9pcs / ctn
Carton Size: 1185 x 325 x 350mm
GW/CTN: 31.81kgs
NW/CTN: 30.33kgs
1800pcs / 20ft container
3700pcs / 40ft container
Delivery Time Shipped in 25 days after payment
Product Description

low price Off grid solar inverter with MPPT and charger 100W-1000W power supply



Main Features

1. Simulated sine wate inverter
2. Sensitivity selector(UPS mode & inverter mode)
3. 10A/20A selectable AC charging current
4. Off mode charging function
5. Auto restart while AC is recovering
6. Cold start function
7. Multiple install options: horizontal, vertical and wall mount
8. Surege, Over load, Short circuit, Over temperture, Over charging Protection
9. Generators & Computer related devices compatible





Technical Specification

ModelSV1200
Capacity1200va / 720w
INPUT
Voltage220/230/240VAC
Voltage Range162-290VAC or 90-290VAC Selectable
Frequency Range 50Hz
OUTPUT
Voltage Ragulation (Bat Mode) ±10%
Frequency Range (Bat Mode)50Hz ± 1Hz
Transfer timeTypical 20ms
Waveform (Bat Mode)Simulated Sinewave
Peak Efficiency(AC Mode)>95% @ FULL R load
Battery
Battery voltage12VDC
AC Charger
Floating Charge Voltage13.7VDC
Max Charging Current10A/20A Selectable
Solar Charger
Solar Charger Input9-40VDC
Solar Charger Output13.7VDC
Solar Charger Current30A/50A Selectable
Power Saving Mode

While solar is charging,AC charger stopps automatically to

save AC power

Protection

Overload,discharge,overcharge,over temperature and

shot circut protection

Full protection
IndicationsColor lcd screen
Display

Indicating line model,battery mode,

input voltage,output voltage,

AC charging mode,solar charging mode,load level,

battery level,and fault etc.

Physical
Dimension,D*W*H(mm)288*272*90
Net Weight (kgs)2.8
Environment
Humidity0-90% Relative Humidity (Non-condending)
Operating Temperature0 ℃ to 50 ℃

 Product Photo









Application

Company Information

 Adavantage:

1.Professional--Over 15 years Professional Power System Producing Experience.

2.Strong R&D team with 15 years experice on Line Interactive UPS and Inverter .

3. More than 10 years experience on exporting business .

Work Shop











Our Services



Customers Service:



(1)Warranty :

A.Our product warranty is valid for 12 months after the date of receiving.

B. We undertake to repair  any  malfunctioned units due to defective components of inadequate workmanship



 (2)Delivery time:

A.sample orders will be delivered in 7 working days since full payment received.

B.General orders(under 2000pcs) will be delivered in 25 working days after downpayment received or L/C received .

c. Bulk orders (over 2000pcs )will be delivered in 30 working days after downpayment received or L/C received .



 (3)shippment :

 By vessel or by freight , For sample order go by EMS, DHL, FedEx, TNT, UPS or other express.



(4)Payment:

 T/T, L/C
