Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: ODM/OEM
  • Model Number: BK line-0003 luminous ups
  • Phase: Single Phase
  • Protection: overload, overcharge, discharge, overload, overcharge, discharge protection
  • Weight: 3.5~4.9kgs
  • Output Voltage: 110/120VAC or 220/230/240VAC
  • Type: Line Interactive
  • Application: Computer
  • Product name: luminous ups
  • Capacity: 450/650/850/1000VA
  • Input voltage: 110/120VAC or 220/230/240VAC
  • Transfer Time: Typical 2-6ms
  • Display: LED or LCD Display
  • Certification: CE/ROSH/UL/TUV/INTERTEK
  • Wave Form: Simulated Sine Wave
  • Battery Type: Inbuilt Lead Acid Battery
  • Material: Plastic case

Packaging & Delivery

Packaging Details one pcs put in one poly bag, together with power line put into one color box for luminous ups
Delivery Time Shipped in 30 days after payment



Product Description

Plastic case 450-1000VA simulated sine wave led/lcd display inbuilt battery luminous ups



Features of our inbuilt battery luminous ups



•Excellent microprocessor control optimizes reliability

•Double boost and buck AVR for voltage stabilization

•Auto restart while AC is recovering

•Off mode charging function

ModelBK450BK650BK850BK1000B
Capacity450VA/240W650VA/360W850VA/480W1000VA/600W
INPUT
Voltage110/120 VAC or 220/230/240 VAC
Voltage Range81-145VAC or 140-300VAC
Frequency Range 60/50 Hz (Auto sensing)
OUTPUT Voltage110/120 VAC or 220/230/240 VAC
AC Voltage Ragulation (Bat Mode) ±10%
Frequency Range (Bat Mode)60Hz or 50Hz ± 1Hz
Transfer timeTypical 2-6ms
Waveform (Bat Mode)Simulated Sinewave
Battery
Battery Type&Number12V 4.5Ah*112V 7Ah*112V 9Ah*112V 9Ah*1
Floating Charging Voltage13.7VDC
Charging ability4-6 hours recover to 90% capacity
Protection
Full protectionOverload,discharge,and overcharger protection
Indications
Line modeGreen lighting
Battery modeYellow flashing
FaultRed ligting
Alarm
Battery modeSounding every 10 seconds
Low batterySounding every second
OverloadSounding every 0.5 seconds
Battery Replacement AlarmSounding every 2 seconds
FaultContinuously sounding
Dimension,D*W*H(mm)279*101*142
Net Weight (kgs)3.54.24.94.9
Environment
Humidity0-90% Relative Humidity 0-40 ℃ (Non-condending)
Noisy LevelLess than 40dB

•Simulated sine wave

•Cold start function

•Compact size




Packaging & Shipping

Packaging and Shipping of luminous ups







Products recommend

 Line Interactive UPS and Inverter recommend





Our Services

 Our services



(1)Warranty :



A.Our product warranty is valid for 12 months after the date of receiving.



B. We undertake to repair  any  malfunctioned units due to defective components of inadequate workmanship



 (2)Delivery time:



A.sample orders will be delivered in 7 working days since full payment received.



B.General orders(under 2000pcs) will be delivered in 25 working days after downpayment received or L/C received .



C. Bulk orders (over 2000pcs )will be delivered in 30 working days after downpayment received or L/C received .



(3)Shippment :



 By vessel or by freight , For sample order go by EMS, DHL, FedEx, TNT, UPS or other express.



(4)Various Certification



RoHS, CE, UL, INTERTEK, TUV, GS, SGS, etc.



(5) Products Application

Computer center, PC, home, mining, industrial, power station, medical, communication, space.

Company Information

 Factory Information

  • Over 15 years experience in power system producing
  • Strong R&D team with 15 years experience in Line Interactive UPS and Inverter
  • More than 10 years experience on exporting business
  • Various stock free sample, free of charge
  • Located in Shenzhen, short distance from train station and port.

FAQ

Frequently asked questions of luminous ups



1.  Why should I choose your factory?

     We have 15 years experience in power system production, 10 years experience in exporting. We're factory with competitive price.



2. Are you ODM/OEM factory?

    Yes.



3. What capacity do you have for line  interactive ups and inverter?

    We have 450/650/850/1000/1500/2000VA for line interactive ups, 1200/2400VA for inverter.  Anyway, you can customize the capacity.



4. Can you ship me a sample?

    Yes, we have many stock free sample, you just need to pay the delivery cost.



5. Is the product safe and environmental?

     Yes, it has overload, overcharge, discharge protection. We got RoHS certification.



6.  Do your products have warranty?

    Of course, 1 year warranty after you received the line interative ups and inverter.



7. What's the difference of Line Interactive UPS and Inverter?

    Inverter has large capacity, can't supply power immediately. Line Interactive UPS has small capacity, can supply power immediately.
